Promoting Key Locations Along a Path

Mappedin previously hosted a webinar titled "Discover the Indoors with Mappedin SDKs". In it, we demonstrated a few unique use cases of the Web SDK. One of the intriguing ideas was highlighting pins along a user's path and displaying additional information as they approached the locations. Here's how you can leverage the SDK to build that.

Webinar Demo

Below is a hands-on with the demo we showed during the webinar. The full source code is available on CodeSandbox.

Notice how highlighted pins appear at locations along the route. As the blue dot (simulating a user) walks near these locations along the path, a new window appears with more information.

Now that you've seen it in action, let's dive into how you could build this feature into your own application.

Promoting Key Locations

To begin picking out locations along your path, you first need to select a start and end location and generate the directions. Then, iterate through the directions.path array to get the nearby nodes along the route. You can check the nodes against an external data set to determine if they should be promoted and add them to the list.

Copy
const promotions = getPromotions(); // Get promotions from external source
const directions = startLocation.directionsTo(endLocation);
const adLocations = [];

directions.path.forEach((direction) => {
  // Get the possible paths for each node along our route
  direction.paths.forEach((node) => {
    const location = mapView.getPrimaryLocationForPolygon(node.polygon);
    // Find the promotion name that matches the location name
    const promotion = promotions.find((p) => p?.name === location?.name);
    // Add to our list
    if (location && promotion) {
      adLocations.push({ location, node, promotion });
    }
  });
});

With the list generated above, you can now create markers which highlight the locations on the map. You can style these markers however you like, adding supplemental text and images about the promotion. This is also a good time to draw the path that navigates past these locations too.

Copy
adLocations.forEach((l) => {
  mapView.createMarker(
    l.node,
    `<div id="promotion">
      <p>${l.promotion.name}</p>
      <div id="pin">
        <div class="img-wrapper">
          <img src="${l.promotion.logo}" />
        </div>
      </div>
    </div>`
  );
});
mapView.Journey.draw(directions);

Detecting Nearby User

In addition to promotion markers, you can detect when a user is within range of a location to display a sponsored message. To achieve this, you can use the blue dot POSITION_UPDATE event which fires whenever a change in the user's position is detected. By converting our position data to MappedinCoordinate we gain access to the absoluteDistanceTo function. Using this, you can choose an optimal distance to display the ad.

Copy
mapView.BlueDot.on(E_BLUEDOT_EVENT.POSITION_UPDATE, (blueDot) => {
  if (!blueDot.position) return;
  const currentCoordinate: MappedinCoordinate =
    mapView.currentMap.createCoordinate(
      blueDot.position.coords.latitude,
      blueDot.position.coords.longitude
    );

  // Check if we are near an ad-enabled location
  let nearAdNode = false;
  adLocations.forEach((l) => {
    const adNode: MappedinCoordinate = mapView.currentMap.createCoordinate(
      l.node.lat,
      l.node.lon
    );
    if (currentCoordinate.absoluteDistanceTo(adNode) < 20) {
      placeAd(l.promotion);
      nearAdNode = true;
    }
  });

  if (!nearAdNode) {
    clearAd();
  }
});

That's really all there is to it. If you're curious how we simulate blue dot positioning, have a read of our Generating Blue Dot Testing Data blog post or fork this webinar demo on CodeSandbox.

If you missed this past webinar, be sure to follow us on LinkedIn and explore our Developer Portal to stay up to date and see more exciting demos like this!
